877-877-2269 | BLACKBOX.COM
Page 9
Chapter 4: Installation
4. Installation
• Find a location suitable for installing the A/B Switch, with access to AC power and the connections you intend
to switch through the unit.
• If you intend to use serial control (SW1046A), connect a serial cable to the DB9 RS232 console port. The baud
rate is fixed at 9600 baud, no parity, 8 data bits, and 1 stop. See Table 6-1 for the console port connector pin
assignments.
• If you intend to use external dry contact closures to control the A/B Switch, connect the external contacts to
the 6-position terminal block as described in Section 5.2.
• Connect the provided 12-VDC power supply to an AC source and to the 2.1 x 5.5 power connector on the A/B
Switch. When power is first applied, it is recommended that the user change connection states on the A/B
Switch from A to B and back again to be sure that all the relays are in a known state, prior to connecting any
external devices. Press and hold (for approximately 1 second) the appropriate front panel pushbutton switch
until the A/B Switch changes connection state. One of the LEDs, A or B, on the front of the unit will indicate
the selected connection state and also serves to show that the switch has power.
• Connect RJ-45 cables DB9 cables between the A, B and C ports on the switch and your devices. The A/B
Switch connects the C (Common) port to either the A or B port.
NOTE: The A/B Switch ports provide straight thru connections and are bidirectional, i.e. they have no preference
to signal direction. If your application requires a crossover cable, use only 1 cross-over cable in that path.
Use a straight through cable on the other side of the switch.
• If you are connecting the Ethernet control interface on the A/B Switch (SW1046A) to your network, you must
first set the IP address, subnet mask and gateway address parameters of the A/B Switch using the serial port.
You should set these parameters before attaching a cable to the NETWORK port, as the default parameters
may not work or could interfere with the operation of your Ethernet network. See Section 6 for more
information regarding IP setup.
