CH APTER 3: INSTALL ATION
3.3 PREPARING YOUR SITE
Before installing the USB 3.1 Extender, you will need to prepare your site:
1. Place the computer where desired and set it up.
2. Locate your USB device(s) within the cable-length of the computer. If not, adjust the location of your device(s) and/or computer
accordingly.
NOTE: If you are using surface cabling, the USB 3.1 Extender supports a maximum distance of 328 feet (100 meters). Install the CAT6a/7
cabling as desired and terminate it with the appropriate RJ-45 ends. If using premise cabling, (in-building network infrastructure),
ensure your cabling is installed between the two locations and does not exceed 328 feet (100 meters) and that it meets the
CAT6a/7 specification.
Cable installation is important, particularly if high throughput applications are used. When installing, ensure the cable is installed away
from, or isolated from potential sources of interference such as electrical wiring, fluorescent lighting, etc.
NOTE: When terminating cables, ensure the matching RJ-45 connector is used for the cable type. For example, if CAT6a cable is used,
then CAT6a compatible RJ-45 connectors must be used. Otherwise, the benefits of using higher-grade cabling may not be
realized.
3.4 INSTALLING THE LOCAL EXTENDER
1. Place the Local Extender near the computer.
2. Assemble the power adapter and country specific power cord together and connect them into a suitable AC outlet.
3. Connect the supplied USB 3.1 Gen cable between the Local Extender host port and a USB 3 port on the host computer.
3.5 CONNECTING THE LOCAL EXTENDER TO THE REMOTE EXTENDER
With Surface Cabling:
1. Plug one end of the CAT 6a/7 cable (not included) into the Link port on the Local Extender.
2. Plug the other end of the CAT 6a/7 cable into the Link port on the Remote Extender.
With Premise Cabling:
1. Plug one end of a CAT 6a/7 patch cord (not included) into the Link port on the Local Extender.
2. Plug the other end of the patch cord into the CAT 6a/7 information outlet near the host computer.
3. Plug one end of the second CAT 6a/7 patch cord (not included) into the Link port on the Remote Extender.
4. Plug the other end of the patch cord into the CAT 6a/7 information outlet near the USB device.
NOTE: Do not exceed more than 32.8 feet (10 meters) total of patch cable when using premise cabling.
3.6 INSTALLING THE REMOTE EXTENDER
1. Place the Remote Extender near the USB device(s).
2. Assemble the power adapter and country-specific power cord together and connect them into a suitable AC outlet.
3. Connect the power adapter to the Remote Extender.
