48
c. You can make a RS422 Daisy Chain multiple camera connection with an RS422 standard serial port
controller.
PELCO P/D Keyboard RS485 Connection
NOTE: Use RS422 ports for RS485 connection. Only use TX+ and TX- for a RS485 connection.
1. On the base DIP switch:
• Set the RS422 control method.
• Set the the Baud Rate to the same setting as the keyboard you are using.
2. Set the camera ID on the OSD menu by remote controller
3. Reboot the camera by turning it O and On after the DIP switch has been set up correctly.
4. Use a PELCO P/D compatible keyboard.
5. Use preset 95# on the keyboard to display/exit the camera OSD menu.
6. Use the joystick and button “OPEN” or “CLOSE” to navigate OSD menu.
