Je bekijkt pagina 15 van 24
Art. 84-0058
15
© 2024-10-17 Biltema Nordic Services AB
FI
Lataa akku aina vain laitteen mukana toimitetulla
verkkolaitteella.
Akun voi ladata sekä imuriin asennettuna että irrallaan.
Imurointi
Kytke imuri päälle ON/OFF-painikkeella.
Valitse imuteho sen mukaan, mitä aiot imuroida. Pieni
teho sopii herkille materiaaleille, kuten pitkänukkaisil-
le matoille. Suuri teho sopii lyhytnukkaisille matoille
ja lattioille. Pieni teho on oletustila, joka on valittuna
aina, kun imuri käynnistetään.
Suulakkeet
▋
Name of each part
1. Electric floor brush 2. Floor brush release button
3. Conductive tube 4. Conductive tube release button
5. HEPA 6. Cyclone
7. Dust bucket 8. Dust removal button
9. Dust bucket release button 10. Main frame
11. Gear adjustment button 12. Switch button
13. Handle 14. Battery pack release button
15. Battery pack 16. Charging socket
17. Hanger 18. Expansion screw
19. Floor brush motor 20. Adapter
21. Long flat suction 22. Combination suction
Lattiasuulake: Lattiat ja matot.
Rakosuulake: Ahtaat tilat ja nurkat.
▋
Name of each part
1. Electric floor brush 2. Floor brush releas e button
3. Conductive tube 4. Conductive tube release button
5. HEPA 6. Cyc lone
7. Dust bucket 8. Dust removal button
9. Dust bucket release button 10. Main frame
11. Gear adjustment butt on 12. Switch button
13. Handle 14. Battery pack release button
15. Battery pack 16. Charging socket
17. Hanger 18. Expansion screw
19. Floor brush motor 20. Adapter
21. Long flat suction 22. Combination suction
Yhdistelmäsuulake: Sohvat, huonekalut ym.
Tyhjentäminen
Imurissa ei ole pölypussia. Tyhjennä imuri avaamalla
pölysäiliön luukku ja kaatamalla pöly pois.
9. HUOLTO JA KUNNOSSAPITO
Suodattimen puhdistaminen
VAROITUS!
• Ota akku pois aina ennen imurin puhdistamista.
• Imuria ja verkkolaitetta ei saa
upottaa veteen.
1. Irrota akku painamalla akun vapautuspainiketta.
Ota akku pois imurista.
2. Irrota säiliö painamalla säiliön irrotuspainiketta.
3. Poista suodatin.
▋Cleaning and replacing parts
·Pour ash for daily use
Press the conductive tube release button, take off the host, and then press the
bottom cover release button of the dust cup to open the bottom cover to pour the
ash (recommendation: pour the ash in time after each use).
·
Dust cup cleaning
a) Press the conductive tube release button, remove the host, and then press the
dust cup release button to separate the dust cup from the motor assembly, and then
press the bottom cover release button of the dust cup to open the bottom cover to
pour dust.
b) Take out the filtered HEPA and take out the cyclone cone.
c) Filter HEPA with clean water and add a small amount of water to clean it and put it
in the container for rinsing. Be careful not to rub HEPA vigorously, so as not to
damage the structure of the filtered HEPA and affect the filtering effect. Please place
the cleaned filtered HEPA in a ventilated place and dry it before using it again. .
(Figure below)
d) The dust buc
ket, dust bucket bottom cover, and cyclone separation cone can be
directly rinsed with tap water and can be used after drying.
e) After pouring the ash, close the bottom cover of the dust cup, and then install the
dust cup and the motor assembly.
·Electric floor brush cleaning
1. Roll the left side slide button on the reverse side of the floor brush to the outside,
and lift the slide button locking blo ck. (As shown below)
2. Take out the roller brush from the slot and clean it up (not w
ashable).
3. After cleaning, assemble in the reverse order of disassembly, an d reset the roller
brus h cove r.
——Caution: After the roller brush is used for a long time, its roller bristles may be
entangled with lo ng flocs such as hair, so it needs to be cleaned in time so that the
vacuum cleaner can work more effectively.
4. Huuhtele suodatin. HUOM! Älä asenna suodatinta
takaisin, ennen kuin se on täysin kuiva!
5. Asenna suodatin takaisin säiliöön ja säiliö sitten
imuriin.
Harjan puhdistaminen
1. Irrota suulake imuputkesta painamalla putken
painiketta ja vetämällä putkea ylöspäin.
2. Irrota tela suulakkeesta avaamalla harjan alapuo-
lella oleva salpa.
▋
Cleaning and replacing parts
·Pour ash for daily use
Press the conductive tube release button, take off the host, and then press the
bottom cover release button of the dust cup to open the bottom cover to pour the
ash (recommendation: pour the ash in time after each use).
·
Dust cup cleaning
a) Press the conductive tube release button, remove the host, and then press the
dust cup release button to separate the dust cup from the motor assembly, and then
press the bottom cover release button of the dust cup to open the bottom cover to
pour dust.
b) Take out the filtered HEPA and take out the cyclone cone.
c) Filter HEPA with clean water and add a small amount of water to clean it and put it
in the container for rinsing. Be careful not to rub HEPA vigorously, so as not to
damage the structure of the filtered HEPA and affect the filtering effect. Please place
the cleaned filtered HEPA in a ventilated place and dry it before using it again. .
(Figure below)
d) The dust buc
ket, dust bucket bottom cover, and cyclone separation cone can be
directly rinsed with tap water and can be used after drying.
e) After pouring the ash, close the bottom cover of the dust cup, and then install the
dust cup and the motor assembly.
·Electric floor brush cleaning
1. Roll the left side slide button on the reverse side of the floor brush to the outside,
and lift the slide button locking block. (As shown below)
2. Take out the roller brush from the slot and clean it up (not w
ashable).
3. After cleaning, assemble in the reverse order of disassembly, and reset the roller
br us h c ove r.
——Caution: After the roller brush is used for a long time, its roller bristles may be
entangled with long flocs such as hair, so it needs to be cleaned in time so that the
vacuum cleaner can work more effectively.
3. Nosta lukko ja tela pois.
4. Puhdista tela. Älä huuhtele telaa vedellä.
5. Laita tela takaisin paikalleen irrotustavan mukaan.
10. ELEKTRONIIKKAJÄTE
Käytetyt sähkö- ja elektroniikkatuotteet, myös kaikki
akut ja paristot, on toimitettava kierrätykseen. (Direk-
tiivit 2012/19/EU ja 2006/66/EY.)
LI-ION-AKKU
Tuotteessa on litiumioniakku. Akkua ei saa niellä,
avata, murtaa, polttaa eikä altistaa korkeille lämpö-
tiloille.
