© 2021 DELTA T LLC Ι ALL RIGHTS RESERVED. 13
Before installing the airfoils, use the provided T-handle hex key to loosen the six
recessed hex bolts above each number. Do NOT loosen the six Phillips head screws
below each number. Loosen all six recessed hex bolts until both yellow tabs have
descended as far as they will go (Fig. 13.2). The airfoils cannot be inserted into the motor
unit until all six hex bolts are fully loosened and both yellow tabs are all the way down.
Fig. 13.2
Make sure both yellow tabs are all the way down.
Recessed Hex Bolt
T-Handle Hex Key
