 67

CARE OF YOUR MACHINE

Cleaning the Hook Race and Feed Dog

WARNING:

Turn the power switch off and unplug the machin before

cleaning.

The machine must only be disassembled as described in

this section.

CAUTION:

Do not store the machine in a high-humidity area, near a

heat radiator, or in direct sunlight.

Installing the Bobbin Holder

Insert the bobbin holder so that the knob ﬁts next to

the stopper in the hook race.

Insert the bobbin.

Attach the stitch plate with the setscrews . After cleaning

the machine, make sure the needle and presser foot are

attached.

Bobbin holder

Stopper

Knob

Screwdriver

Setscrews

Press the needle stop up/down button to raise the needle. Turn off

the power switch.

Remove the needle and presser foot.

Remove the setscrew out of the left side from the stitch

plate . Use theT screwdriver supplied with the machine.

Remove the stitch plate .

Remove the bobbin. Lift up the bobbin holder and remove

it.

Clean the bobbin holder with a lint brush .

Clean the feed dog , thread cutter mechanism and hook

race with the lint brush.

Clean the center of the hook race with a dry cloth.

Screwdriver

Setscrews

Stitch plate

Lint brush

Thread cutter mechanism

Bobbin holder

Feed dog

Hook race

(You may also use a vacuum cleaner.).

* The machine does not require oiling.

PLEASE NOTE:

Clean the outside of the machine with a soft cloth and

soap.

After cleaning the machine, make sure the needle and

presser foot are attached.
