18

Second spool pin

The second spool pin is for winding bobbins without unthreading

the machine.

Insert the second spool pin into the hole.

The second spool pin should point to the bobbin winder tension

disc.

Draw the thread from the spool and pass the thread around the

bobbin winding tension disc as shown.

Second spool pin

Hole for second spool pin

Bobbin winder tension disc

Bobbin Winding and Inserting

• Removing the bobbin

Gently slide the hook cover release button to the right and

remove the hook cover plate.

Lift out the bobbin.

Hook cover release button

Hook cover plate

Bobbin

PLEASE NOTE:

Use the “J” plastic bobbins for horizontal hook (marked

with “J” ). Using other bobbins, such as pre-wound

paper bobbins, may cause stitching problems and/ or

damage to the bobbin holder.

• Setting the Spool of Thread

Horizontal spool pin

Lift up the spool pin. Place a spool of thread on the spool pin.

Attach the large spool disc, and press it ﬁrmly against the spool

of thread so that the spool rests on the supporter.

Spool pin

Spool

Large spool disc

Supporter

The small spool disc is used with narrow or small spools of

thread.

Small spool disc

• Spool net

Polyester or bulky nylon threads become loose while unwinding.

To keep consistent feeding of such threads, pull the spool net over

the spool.
