-6-

NOTE: For Electric, Steam and Hot Water heated air curtains

provided with an optional remote thermostat, mount and

wire the thermostat according to thermostat instructions

and wiring diagram.

For Programming multiple air curtains from a single source,

there are two options:

1. Interconnect Connection (aka daisy chain) via

physical connection, see Appendix A. NOTE: The air

curtain must have been ordered from the factory with

the Interconnect physical data link option.

2. Grouping via the Berner AIR app,

see Section VII - Operating Instructions.

NOTE: All Architectural Recessed air curtains include

the Berner AIR smart control & app.

For Remote Mounted Intelliswitch™ Touchscreen Display or

Touchscreen Tablet (ordered separately), see Appendix B.

NOTE: The air curtain must have been ordered from the

factory with Remote Mounted Intelliswitch™ Touchscreen

Display or with the factory installed PoE for connection to

a touchscreen tablet.

For BACnet or Modbus Integration, see Appendix C.

For Electric, Steam and Hot Water air curtains, see

Section VI - Field Connections, otherwise proceed to

Section VII - Operating Instructions

A. ELECTRICALLY HEATED MODELS

The heater circuit may be controlled by an optional

remote thermostat or through the built-in Intelliswitch™

temperature probe located on top of the air curtain.

Overheating protection is provided by auto reset thermal

cutouts built into the heater coil assembly (see the wiring

diagram attached to the screen in a small bag).

See Figure 8.

NOTE: Maximum mounting distance between the Display

Faceplate and the air curtain is 6096mm.

1. When the remote faceplate option is ordered from the

factory, the air curtain comes equipped with the blank

faceplate already installed and the 6096mm ribbon

cable attached. The Display Faceplate is shipped loose,

ready for eld installation.

2. Locate the male end of the conductor ribbon cable

and run it to the remote display location. The cable

is minimum CL2 rated and should not need to be in

conduit.

3. Connect the female end of the ribbon cable to the 14-

pin socket on the back of the display board with the

cable approaching from the top and the red ribbon

indicator to the right (when facing the front of the

display board).

4. Mount Display Faceplate to the wall.
