Berbel Ergoline 2 BKH 110 EG-2 Handleiding (132 Pagina's)

Handleiding

116

Installation

6006910_0 – 18.11.2023

a

b

a = 7

b = 3-6

The top fastening screws should only be tightened once the

device has been aligned.

The lower fastening screws prevent the device pulling away

from the wall and are no longer accessible after the device is

hung in place.

1 Tighten the mounting screws appropriately.

. WARNING!

Danger of injuries through improper handling!

Hanging the device requires a great deal of physical exertion

due to its size and weight. If the device falls down, serious

injuries are possible.

1 Two persons are required to hang the device.

1 Ensure stable footing when hanging the device.

1 Ensure that no other people are in the working area.

. ATTENTION!

Danger of property damage through improper handling!

Hanging the device requires a great deal of physical exertion

due to its size and weight. If the device falls, the device,

kitchen furnishings and other objects could be damaged.

1 Cover the cooled hob.

1 Keep the installation area clear.

1 Hang the device on the mounting points.

1.

2.

3.

1.

2.

3.

1 Check the horizontal alignment of the device.

1 Align the device with the adjusting screws.

1 Tighten the mounting screws.
