Handleiding

114

Installation

6006910_0 – 18.11.2023

3.4.3 Removing the lower section, bulging edge and

CapillarTrap

. ATTENTION!

Danger of property damage through falling parts!

When moving the device, the front panel may open and

parts lying inside could fall out.

1 Remove the parts lying inside before installation.

The lower section is secured in the end positions and can

only be removed in a central position.

1.

2.

1 Open the front panel.

1 Fold the lower section into a central position.

1 Draw the lower section up and out.

The bulging edge is attached and held in the device by

magnets.

1 Pull the bulging edge from the upper section.

The Capillar Trap is inserted and is held in the device through

a side lock.

1 Grasp the Capillar Trap on its sides with both hands.

1 Pull the Capillar Trap out in a bow movement.
