Handleiding

113

Installation

6006910_0 – 18.11.2023

EN

3.4 Installation procedure

Short overview:

1. Preparation for installation

2. Unpack the device

3. Removing the lower section, bulging edge and

Capillar Trap

4. Hang the device in place

5. Install filter

6. Establish electrical power supply

7. Mounting the chimney

8. Insert the Capillar Trap, bulging edge and lower section

9. Check and carry out commissioning

3.4.1 Preparation for installation

1 Familiarise yourself with the installation situation and the

associated documents.

2 Device and instructions.

2 Installation location.

1 Assemble the tools and materials required:

2 Stable stepladder

2 Folding rule or measuring tape

2 Pencil

2 Spirit level

2 Slotted screwdriver SL 2.5 x 0.4

2 Torx screwdriver TX30

2 Ø 8 mm masonry bit

2 Hammer drill

2 10 mm spanner

2 Protective material (e.g. thick cardboard) for the hob

and the worktops

1 Keep the installation area free of objects that could be in

the way or that could be damaged.

1 Make sure that the hob and other parts that could be

touched have cooled down.

1 Protect the hob and other surfaces in the installation area

(e.g. with thick cardboard).

1 Ensure that the power supply is switched off and remains

so. Connect the power supply only when instructed to do

so in the installation instructions.

3.4.2 Unpack the device

. ATTENTION!

Hazard of glass breaking or other damage due to

incorrect handling!

The device and its surfaces can be damaged when being

unpacked or transported.

1 Do not cut into the protective cardboard packaging.

1 Keep objects that could scratch the device far away from

it (e.g. tools, belt buckles).

1 Unpack the device and all accompanying parts carefully.

1 Place the device on its back on a firm, clean and

protective surface (e.g. thick cardboard).

1 Check the device and its constituent parts for damage.

1 Check the delivery is complete.

, “2.4 Scope of delivery” (page 110).

If parts are missing or damaged:

1 Please consult the customer services.

1 Remove the packaging material and the protective film.

, “8.1 Dispose of packaging” (page 130).
