13
Installation
6005077_a – 24.02.2020
EN
a
a
b
b
a = 7
b = 3-6
The top fastening screws should only be tightened once the
device has been aligned.
The lower fastening screws prevent the device pulling away
from the wall and are no longer accessible after the device is
hung in place.
☞ Tighten the mounting screws appropriately.
D WARNING!
Danger of injuries through improper handling!
Hanging the device requires a great deal of physical exertion
due to its size and weight. If the device falls down, serious
injuries are possible.
☞ Two persons are required to hang the device.
☞ Ensure stable footing when hanging the device.
☞ Ensure that no other people are in the working area.
D ATTENTION!
Danger of property damage through improper handling!
Hanging the device requires a great deal of physical exertion
due to its size and weight. If the device falls, the device,
kitchen furnishings and other objects could be damaged.
☞ Cover the cooled hob.
☞ Keep the installation area clear.
☞ Hang the device on the mounting points.
1.
2.
3.
2.
3.
☞ Check the horizontal alignment of the device.
☞ Align the device with the adjusting screws.
☞ Tighten the mounting screws.
