24 / EN
Floor standing type air conditioner / User Manual
• Confirm the following points:
- Unit type/Power supply specification
- Pipes/Wires
- Accessory items
6.5 Installation location
6.5.1 Location for installing
indoor unit
1. No obstacle around the air outlet and air flow
can spread to the whole room.
2. It is easy to arrange connection pipe and drill
a wall hole.
3. Keep a required distance from the ceiling
and wall as illustrated on the figure of the
previous page.
4. Easy to take down and install the air filter.
5. Keep the unit a distance of over 1 meter away
from a TV set, radio etc. that may arouse
interference.
6. Do not put anything around the air intake.
7. Install it at a place that can bear the weight of
it and would not increase noise and vibration
during operation.
8. Avoid installing it where there is much oily
smoke, salty, sulfide gas, dust and direct
sunlight.
Indoor unit
Max. length
Outdoor unit
Max drop height L
6.5.2 Location for installing
outdoor unit
1. Install it at a place where it is convenient for
installation and well ventilated.
2. Keep the required distance away from the
wall as reqiured on the previous page when
carrying on installation.
3. Pipe length and drop height should comply
with the scope required below.
Model
Capacity
(Btu/h)
Max. Pipe
Length (m)
Max. Height
Length (m)
24K 30 20
36K/48K 50 30
4. When operating at a special place, for
example, a place of greasy dirt, vulcanization
gas or high-salty seashore, make sure to
adopt an effective isolation measure.
5. Avoid installing it on the roadside where there
is a risk of muddy water.
6 Installation and maintenance
