THANK YOU FOR BUYING A HOTPOINT ARISTON PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.register10.eu
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code in your appliance
• Visiting our website docs.hotpoint.eu and parts-selfservice.europeanappliances.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales
Service, please state the codes provided on your product's identi cation plate.
You can nd more information about your model online at https://eprel.ec.europa.eu/ which is the o cial EU EPREL product database.
After selecting the Product Category, enter the Model Identi er of the product. The Model Identi er is made up of letters and numbers
and can be found on the identi cation plate, as Mod. (see image on the right).
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code in your appliance
• Visiting our website docs.emeaappliance-docs.eu
• Alternatively, contact our After-sales Service (Using QR code in your appliance). When contacting our After-sales Service, please
state the codes provided on your product's identi cation plate.
EN
Before using the appliance carefully
read the Safety Instruction.
PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.
Quick guide
Before using the appliance carefully
read the Safety Instruction.
Power consumption
o-mode (Po) - Watts 0.42
left-on mode (Pl) - Watts 2.00
Programs kg kWh Minutes
Eco*
8 1.95 194
Eco
4 1.06 135
Synthetics 4 0.73 95
*The ECO is the most ecient programme in terms of energy
consumption for drying wet cotton laundry, and is used to assess
compliance with Regulation (EU) 932/2012.
Cleaning the tumble dryer
• The external metal, plastic and rubber parts can be cleaned
with a damp cloth.
• Clean the front air intake grille regularly (every 6 months) with
a vacuum cleaner to remove any lint, u or dust deposits.
Furthermore, remove any lint deposits from the lters area,
using a vacuum cleaner every so often.
• Do not use solvents or abrasives.
AB
1
4
2
3
C
C1 C2 C3
C4
C5
C6
CLEANING AND MAINTENANCE
WARNING: unplug the dryer during the cleaning and
maintenance procedures.
Emptying the water tank after each cycle (see Fig. A).
Pull the container out of the dryer and empty it into a sink or
other suitable drain, then place it back properly. Do not use the
dryer without having inserted the container back in place.
Cleaning the lters
Take out the lters and clean them by removing the lint from their
surfaces with your hand or a cloth or using a vacuum cleaner, then
put them back in place. The lint should be thrown in the garbage
bin and not washed through the drain in order to avoid spreading
microplastics in the used water system.
Do not use the dryer without having reinserted the lter in place.
Cleaning the door lter after each cycle (see Fig. B).
Remove the door lter as described below:
1. Open the door and pull the lter upwards.
2. Open the lter and remove the lint from all its parts.
Make sure to also remove any foreign objects inside the lter and
the drum.
Replace the lter correctly making sure it is fully seated.
Cleaning the bottom lter when the relevant indicator
turns on (see Fig. C).
NOTE: however, it is advisable to clean this lter after each cycle
to optimise drying performance.
Remove the bottom lter as described below:
C1. Open the bottom cover; take the handle and pull the lter out.
C2. Open the rear side of the lter and remove the lint from the
inner surface of the mesh.
C3/C4. Check the bottom lter chamber every month. If you
see residual lint accumulated on the metal ns, clean it with a
vacuum cleaner, using a nozzle with a brush.
It's crucial to do vertical movements, you may destroy the
component if you try to clean it in horizontal direction. Avoid the
direct contact of the hand with the ns - risk of cut.
C5. Close the rear side of the lter and place it back by checking it
is perfectly integrated into its seat, then lower the lter handle.
C6. Close the bottom cover.
Make sure the air intake is free.
The lters are essential parts for drying. They are intended
to collect the lint formed during the drying process. In case
of clogged lters, the air ow inside the dryer would be
seriously aected: the drying times would be longer, the
energy consumption would increase and the dryer could be
damaged. If these procedures are not carried out properly,
the dryer may not start.
TRANSPORT AND HANDLING
Never lift the dryer by holding it at the worktop.
1. Unplug the dryer.
2. Remove the water from the water tank completely.
3. Make sure that door and water tank are properly closed.
4. If the drain hose is connected to your drainage system,
re-connect it to the back of the dryer (see "Installation" section
in the Safety Instruction guide).
PRODUCT DESCRIPTION
1. Water Tank
2. Air Intake
3. Bottom lter
4. Door lter
NOTE: After cleaning the lters the relevant indicator remains on;
this is normal, it will disappear when you start a new drying cycle.
