R59xxxx /00 IBX
IBX SERIES
7
Maximum tiles per
power cable
Tile
Power source
India
IBX1.2
100 – 180 VAC
12 tiles
180 – 240 VAC
20 tiles
IBX1.5
100 – 180 VAC
12 tiles
180 – 240 VAC
20 tiles
IBX1.8
100 – 180 VAC
12 tiles
180 – 240 VAC
20 tiles
IBX2.5
100 – 180 VAC
12 tiles
180 – 240 VAC
20 tiles
The power limits of the used power connectors needs to be followed.
ESD and LED's:
LED components used in IBX tiles are ESD (Electro-Static Discharge) sensitive. To prevent the possibility of
destroying LED components, do not touch either in operation or while switched off. Always use ESD-gloves.
Disconnect device:
When the appliance inlets of the individual tiles are not accessible, the socket outlets supplying the rack shall be
installed near the equipment and be easily accessible, or a readily accessible general disconnect device shall be
incorporated in the fixed wiring.
This equipment MUST be earthed:
In order to protect against risk of electric shock, the installation should be properly grounded. Defeating the
purpose of the grounding type plug will expose you to the risk of electric shock.
Power system:
It is recommended to use a TN-S power distribution system (a power distribution system with a separate neutral
and grounding conductor) in order to avoid large ground current loops due to voltage differences in the neutral
conductor. The total electrical installation should be protected by an appropriately rated disconnect switch, circuit
breakers, over voltage protector and Ground Fault Current Interrupters. The installation shall be done according
to the local electrical installation codes. In Europe special attention should be given to HD 60364, Harmonization
Document for electrical installation of buildings. In Germany VDE 0100 should be adhered to. In America, special
attention should be given to the National Electrical Code, ANSI/NFPA 70.
Mains cords:
The power cords delivered with this system have special properties for safety. They are not user serviceable. If
the power cords are damaged, replace them only with new ones. Never try to repair a power cord.
LEDs:
The LEDs used on the IBX tiles are fragile. Never push with a hard or sharp object onto the lens of the LED as
this may cause damage to the LED. The maximum allowed load upon the lens of the LED is 300 gram/LED.
Do not hot plug:
Do not hot plug any cables. Damage to the connector pins may occur. Resulting damage is not covered under
warranty.
Maximum allowed display height:
There is no limit to the maximal height of the IBX display for a wall mount configuration as the weight of each
tile is being borne by the wall mount structure and hence distributed along the entire wall surface. However,
installer needs to ensure that the wall structure is capable to withstand the load of the entire wall.
1.4 Proper usage
Proper usage of IBX tiles
• No part of the IBX tile can come in contact with any type of moisture.
• No part of the IBX tile can come in contact with any type of abrasive.
• No part of the IBX tile can come in contact with any type of dust.
• No part of the IBX tile can come in contact with any type of corrosive substance.
• Do not incline, scratch, or crash the LED display during installation.
• Do not direct the air outlet of an air conditioner to the LED display.
• Do not place or use the LED display in an environment with volatile, corrosive or flammable chemical products.
• Using the LED product in an environment with high corrosive gasses (e.g. Sulphur) can lead to discoloration of
the materials. This discoloration gives a change in brightness of the product. This could lead to uniformity
differences and possibly also to failures. Each use of the product in this kind of environment needs to be checked
up-front with the supplier.
• IBX tiles are to be used in environments meeting the operating specifications.
• IBX tiles are not to be used in environments that are subject to airborne contaminants such as that produced
by smoke machines (cracked oil) or similar (these deposit a thin layer of greasy residue upon the LEDs optics,
degrading performance).
• IBX tiles are not to be exposed to extreme localized heat or cold exceeding the temperature specifications.
