• Off: Press PTT to turn it off. That is, the current channel or VFO mode disables DTMF signaling.

• BOT: The code is sent when you press the PTT.

• EOT: The code is sent when the PTT is released.

• BOTH: The code is sent when you press and release the PTT.

(22) Signal code sending delay (PTT-DLY) – MENU + 22

PTT-ID signal code sending delay time setting, range 100-3000ms.

(23) 1750Hz Repeater Tone (ALERT) – MENU + 23

With this functio

n you can select 1000Hz, 1450Hz, 1750Hz, 2100Hz repeater tone. To send out a repeater tone; You hold down the [PTT] + key.

If you have the keypad lock enabled on your radio, you can still send a 1750Hz tone the regular way without having to unlock your radio.

(24) Squelch tail elimination (TAIL) – MENU + 24

This function is used eliminate squelch tail noise between handhelds that are communicating directly (no repeater). Reception of a 55 Hz or 134.4 Hz tone

burst mutes the audio long enough to prevent hearing any squelch tail noise.

(25) SK2 function d

efinition(Press SK2) – MENU + 25

The SK2 key allows users to customize functions:

• FM RADIO: Quickly turn on or off the FM radio function.

• Scan: Quickly turn on or off the scan function. You can also turn on or off the scan function by hold down the # key.

• SEARCH: Quickly turn on or off the one-touch frequency search function.

• VOX: Quickly turn on or off the VOX function.

(26) Reset (Reset) – MENU + 26

With this function you

can reset the transceiver to the factory-programmed settings and parameters. After that, you can set the desired functions. There are

two types of reset:

• VFO: Menu Reset

• ALL: Menu and channel Reset

7.4 Program Channel

Channel configuration is only applicable to the current channel and will not change the configuration parameters of other channels. It allows to modify the

channel name, Receive or Transmit frequency, Tx_Rx CTCSS/DCS

, add the current channel to the scan list, Working Mode, and channel memory and

channel delete.

(1) Channel name (CHNAME) – MENU +1

To set the channel name you have at your disposal 26 letters (A-Z) and 10 numbers (0-9). You can use up to 8 characters for the channel name.

Edit the desired channel name with the keypad and then confirm by pushing

key. To exit the function press key.
