regardless of scanner resume method.

To enable the scanner, press and hold the

key for about two seconds.

Short press the

key to quickly enter the DTMF dial.

5.BASIC OPERATIONS

5.1 Power on the radio

• Turning the unit on

To turn the unit on, simply rotate the Volume/Power knob clockwise until you hear a "click". If your radio powers on correctly there should be an audible

double beep after about one second and the display will show a message or flash the LCD depending on settings for about one second. Then it will display a

frequency or c

hannel. If the Voice prompt is enabled, the voice will announce "frequency mode" or "channel mode".

• Turning the unit off

Turn the Volume/Power knob counter-clock wise all the way until you hear a "click". The unit is now off.

5.2 Adjusting the volume

To turn up the volume, turn the volume/power knob clock-wise. To turn the volume down, turn the Volume/Power knob counter-clock-wise. Be careful not to

turn it too far, as you may inadverte

ntly turn your radio off.

By using the monitor function, enabled from the [FM broadcast/Monitor] key below the PTT, you can more easily adjust your volume by adjusting

it to the un-squelched static.

5.3 Main Band/Sub Band Switch

In standby mode, press the key to switch between the main frequency band or sub frequency bands.

Those in large font are the main bands and those in small font are the sub-bands.

5.4 VFO/Channel Switch

Press and hold key to switch between VFO and channel display.

• In channel mode (MR), the channel number will be displayed on the right.

• In frequency mode (VFO), the ‘VFO’ will be displayed on the right.

5.5 Frequency (VFO) mode

In Frequency (VFO) mode you can navigate up and down the band by using the  or  keys. Each press will increment or decrement your frequency

according to the frequency step you've set your transceiver to.

You can also input f

requencies directly on your numeric keypad with kilohertz accuracy.

The following example assumes the use of a 12.5 kHz frequency step.
