information list. Press key to switch My Place in the

information list mode or electronic compass mode. Press the

/ key to switch the information of the selected member. The

current Contact sequence will be displayed at the top of the

interface.

Press the key to exit GNSS mode

Find My Place

1. Press and hold key to enter GPS mode.

2. Use the /key to switch to "My Place".

3. At this point, the GPS is in receive mode and displays "Searching" The GPS character on the right is red, indicating that the positioning has not been

successful.

Note: If "Searching" is displayed for a long time, it is recommended that you search for satellites in an open location.

4. Display "Pos Successful" to indicate that the radios position has been successfully obtained, and display the current time, longitude, latitude, and altitude,

Where N is north latitude, E is east longitude, and H is height. The GPS character on the right is green.

5. Press the key to switch between the GPS position information interface and the GPS distance direction interface.

Share My Place information (send to others)

1. After the GPS position of the radio is successful, press the key to switch to the

location information interface.

2. Press the / key to select the pre programmed Contact sequence (01-20), and display

the member sequence and name on the first line. Select the member sequence labeled as

"Host".

3. Press the [PTT] key to share the current location information of the device with group

members.

Requesting someone else's place

1. After the GPS position of the radios is successful, press the key to switch to the My Place information interface.

2. Press the / key to select the pre programmed Contact sequence (01-20), and display the sequence and call name on the first line. Select member

sequences that are not marked as " Host ".

3. Press the [PTT] key to initiate a position request command to the target member.

4. Press the key to switch to the electronic compass interface and display the reference distance between two radios.

-Disable transmission during waiting for reception.
