Presser Foot Pressure Adjustment
The presser foot pressure has been preset and rarely needs adjustment.
You may nd it necessary to decrease the foot pressure for thick fabrics
or increase foot pressure for thin fabrics to feed more smoothly under the
presser foot. Turn the presser foot pressure adjustment dial on the left side
of the machine.
To increase pressure, turn the pressure adjusting dial counterclockwise.
To decrease pressure, turn the dial clockwise.
M
M
6.0
3. 5
3.0
5.5
M
M
6.0
3. 5
3.0
5.5
Stitch Length/Rolled Hem
Stitch Width
The stitch length/rolled hem adjusting dial is conveniently located
just to the left of the front cover, near the base plate (g. A). The dial
shows two stitch length ranges, from 0.75, for the shortest stitch, to
4 for the longest. As the dial indicates, one range is for standard
(overlock stitches) sewing and one is for rolled edging or narrow
hemming/seaming.
Simply turn the dial aligning the desired setting with the indicator
mark on the machine. A stitch length of 3mm, or about 10 stitch
-
es per inch is ideal for seaming and overedging most fabrics. For
overedging or seaming very lightweight fabrics, you may prefer a
shorter stitch length. When sewing heavier fabrics, you may choose
to lengthen the stitch (g. B).
NOTE: 0.75mm is located between the 0 and 1 on both standard &
rolled settings.
The stitch width adjusting dial is located above the stitch length dial
(g. A). The stitch width displays two sets of numbers, indicating two
width ranges. for overlock stitches. The larger numbers on the dial, 5.5
through 7.5mm, denote the stitch width when the O-1 (left) needle is in
use. The smaller size numbers, 3.0 through 5.0mm, apply when only
the O-2 (right) needle is in use for forming a 3-thread or 2-thread stitch.
The "M" setting (3.5) is for the rolled edge.
Adjusting the stitch width moves the upper cutting blade. It also moves
the stitch ngers further apart or closer together for complete
fabric support with any stitch width.
The stitch width is variable between either end of the range. Simply
turn the dial aligning the desired setting with the indicator mark on the
machine. Use a wider stitch width for medium to heavier wovens and
knits and a narrower stitch width for lightweight wovens, knits and sheer
fabrics (g. B).
Note: Each number appears only once on the stitch width dial. The
larger numbers on the stitch width dial indicate a left (O-1) needle po
-
sition with the smaller numbers indicating a right (O-2) needle position.
When using two needles the default will always be the left (O1) needle
position.
AA
AA
BB
BB
63
S
E
A
M
A
D
J
U
S
T
M
E
N
T
