2-Thread Overlock
Converting from 3-Thread to 2-Thread Overlock
The 2-thread overlock stitch provides an economical and less bulky means of overedging all fab-
rics. The standard 2-thread overlock is the same as a 2-thread flatlock stitch.
When sewn with specialty threads, 2-thread sewing makes decorative seams and edges for ac
-
tivewear, and children's hemlines.
Instructions for Upper/ Lower Overlock Needle(s) threading (See pages 19-21 and 23).
Either overlook needle may be engaged for 2-thread overlock sewing.
1. Open the front cover and the cutting blade cover. Cut the upper looper thread just above the
threading port (fig. A).
2. Raise the presser foot and remove the upper looper and needle threads from the machine.
3. Guide the subsidiary looper to the right and swing it counterclockwise to the left (fig. B). Make
sure the hooked tip of the subsidiary looper enters into the upper looper eye (fig. C).
4. Place the left needle thread on the "OVERLOCK NEEDLE 1" spool pin (or right needle thread
on the "OVERLOCK NEEDLE 2" spool pin) and bring the thread through the telescopic anten
-
nae thread guide directly above the spool of thread. Snap the thread into the pretension thread
guide on top of machine that is normally used for the upper looper (3rd from left), and down the
front of the machine.
5. Take the thread to the left and thread the machine as you would for the needles in their normal
position(see illustrations on pages 36 and 37 for correct threading and suggested settings). Us
-
ing the needle threader, thread the eye of the left needle (O-1), or the right needle O-2 (see the
bottom of page 23).
6. Place the looper and needle threads under the presser foot and to the back. Close the cutting
blade cover and front cover.
7. The needle and lower looper threads should lock (evenly) on the cut edge of the fabric.
NOTE: Converting from a 2-thread to 3-thread or 4-thread Overlock disengage the subsidiary
looper, see page 14.
1
2
1
2
1
2
AA
BB
CC
O
V
E
R
L
O
C
K
S
T
I
T
C
H
E
S
35
