Gallant User Manual | 15

Power Cord

To install the power cord

• Insert the plug into the power connector on the rear of the machine. Plug the three-prong plug end

into your power source. Do not turn on the machine unl the handlebars are installed.

To disconnect the power cord

• First pull out on the red buons on the sides of the

plug and then pull the plug out of the machine.

 NOTE: Make sure that the machine is o before

plugging into a power source. The main power

switch should be in the O (o) posion.

Front Handlebars

The Gallant comes with handlebars for the front of the machine. Oponal rear handlebars are available

for quilng with pantographs and Groovy or paern boards. The front handlebars are used for most other

quilng acvies.

U CAUTION: To prevent any electrical damage to the handlebars, always turn o all power to the

machine when connecng or disconnecng the handlebars.

To install the front handlebars

1. Remove the two screws in the front top

cover with a 3mm hex tool. Remove

cover by pulling up on the rear poron

then sliding tabs out in the front.

2. Place four M4x10mm screws with

washers down through the handlebar

into the top of the machine and ghten

them rmly with a 3mm hex tool.

3. Plug the two handlebar cable plugs into

the two jacks in the back top (le plug

to le jack and right to right). The right

handlebar cable is labeled.

4. Push ferrites down into the space so

that the cover will t back into place.

5. Replace the front top cover by sliding

tabs at the front into machine and

angling the rear of the cover down into

place. Tighten the screws with a 3mm

hex tool. Do not over ghten.
