2
CONNECTIONS TO BE MADE
From the 16-pin harness with stripped leads:
• Connect the Red wire to the ignition/accessory wire.
• Connect the White wire to the left front positive speaker wire.
• Connect the White/Black wire to the left front negative speaker wire.
• Connect the Gray wire to the right front positive speaker wire.
• Connect the Gray/Black wire to the right front negative speaker wire.
• Connect the Brown wire to the mute wire of the aftermarket radio. If the radio has no mute
wire, tape it off and disregard it.
• Tape off and disregard the following (6) wires, they will not be used in this application:
Orange/White, Blue/Pink, Green, Green/Black, Purple, Purple/Black
From the GMOS-12 harness to the aftermarket radio:
• Connect the Yellow wire to the 12 volt constant/battery wire.
• Connect the Black wire to the ground wire.
• Connect the Orange wire to the illumination wire of the aftermarket radio.
If no illumination wire is present, tape it off and disregard it.
• Tape off and disregard the Orange/White wire, it will not be used this application.
• Connect the Green wire to the left rear positive speaker wire.
• Connect the Green/Black wire to the left rear negative speaker wire.
• Connect the Purple wire to the right rear positive speaker wire.
• Connect the Purple/Black wire to the right rear negative speaker wire.
• The Black/Yellow wire is for OnStar volume adjustment and will be discussed later
in this manual.
