INSTAXVI-9003
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
INSTAXVI-9003
INSTAXVI-9003 INSTAXVI-9003
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
1-800-221-0932 metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/21/20
AXVI-9003
Volkswagen accessory and NAV output CAN harness 2002-up
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in both amplified and non-amplified systems*
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
*excluding Fender audio systems
APPLICATIONS
WIRING UP THE AXVI-9003
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the orange wire.
• The Blue wire is not used in this application.
AXVI-9003
VOLKSWAGEN
Beetle 2012-up
CC 2009-up
EOS 2007-up
Golf (with double DIN radio) 2002
Golf 2003-2006
Golf/Golf R 2010-up
GTI 2002-up
Jetta (with double DIN radio) 2002
Jetta 2003-up
Jetta GLI 2008-up
Jetta Sportwagen 2010-up
Passat 2002-up
R32 2007-2008
Rabbit 2007-2009
Tiguan 2009-up
Volkswagen accessory and NAV output CAN harness 2002-up
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in both amplified and non-amplified systems*
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
*excluding Fender audio systems
APPLICATIONS
WIRING UP THE AXVI-9003
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the orange wire.
• The Blue wire is not used in this application.
VOLKSWAGEN
Beetle 2012-up
CC 2009-up
EOS 2007-up
Golf (with double DIN radio) 2002
Golf 2003-2006
Golf/Golf R 2010-up
GTI 2002-up
Jetta (with double DIN radio) 2002
Jetta 2003-up
Jetta GLI 2008-up
Jetta Sportwagen 2010-up
Passat 2002-up
R32 2007-2008
Rabbit 2007-2009
Tiguan 2009-up
AXVI-9003
Volkswagen accessory and NAV output CAN harness 2002-up
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in both amplified and non-amplified systems*
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
*excluding Fender audio systems
APPLICATIONS
WIRING UP THE AXVI-9003
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the orange wire.
• The Blue wire is not used in this application.
AXVI-9003
VOLKSWAGEN
Beetle 2012-up
CC 2009-up
EOS 2007-up
Golf (with double DIN radio) 2002
Golf 2003-2006
Golf/Golf R 2010-up
GTI 2002-up
Jetta (with double DIN radio) 2002
Jetta 2003-up
Jetta GLI 2008-up
Jetta Sportwagen 2010-up
Passat 2002-up
R32 2007-2008
Rabbit 2007-2009
Tiguan 2009-up
Volkswagen accessory and NAV output CAN harness 2002-up
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in both amplified and non-amplified systems*
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
*excluding Fender audio systems
APPLICATIONS
WIRING UP THE AXVI-9003
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the orange wire.
• The Blue wire is not used in this application.
VOLKSWAGEN
Beetle 2012-up
CC 2009-up
EOS 2007-up
Golf (with double DIN radio) 2002
Golf 2003-2006
Golf/Golf R 2010-up
GTI 2002-up
Jetta (with double DIN radio) 2002
Jetta 2003-up
Jetta GLI 2008-up
Jetta Sportwagen 2010-up
Passat 2002-up
R32 2007-2008
Rabbit 2007-2009
Tiguan 2009-up
