CONNECTIONS
From the AXVI-6524 harness harness to the aftermarket radio, connect as indicated:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the (3) Red wires to the accessory wire.
Note: If installing an AXSWC (sold separately), there will be an accessory wire there to
connect as well.
• If the aftermarket radio has an illumination wire, connect the Orange wire to it.
• Connect the Gray wire to the right front positive speaker wire.
• Connect the Gray/Black wire to the right front negative speaker wire.
• Connect the White wire to the left front positive speaker wire.
• Connect the White/Black wire to the left front negative speaker wire.
• Connect the Green wire to the left rear positive speaker wire.
• Connect the Green/Black wire to the left rear negative speaker wire.
• Connect the Purple wire to the right rear positive speaker wire.
• Connect the Purple/Black to the right rear negative speaker wire.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
• Tape off and disregard the following (2) wires, they will not be used in this application:
Blue/White (qty. 2)
•
If retaining the factory backup camera, connect the Yellow RCA jack to the backup camera input
.
Note: For Wrangler JL and Gladiator the camera is not retained. You must purchase the
JP-JLKT for the JL and the JP-JTKT for the Gladiator to retain the camera
• If retaining the factory AUX-IN jack, connect the Red & White RCA jacks to the AUX input.
Continued on the next page
