METRA. The World’s best kits.™ metraonline.com1-800-221-0932
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Installation Instructions for AXVI-2104
REV. 1/21/2020 INSTAXVI-2104
(continued on next page)
GM 2006-2012
AXVI-2104
GM LAN 11 accessory and NAV output interface
WIRING THE AXVI-2104
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio.
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• The Orange/White wire will not be used in this application. Tape up or cap off this
wire and disregard it.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
CHEVROLET
Cobalt 2007-2010
HHR 2006-2011
Malibu 2008-2012
PONTIAC
G5 2007-2009
G6 (5th digit of VIN must be a J, K, or L) 2009
G6 2010
Solstice 2006-2009
SATURN
Aura 2007-2009
Sky 2006-2009
APPLICATIONS
KIT FEATURES
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems or when replacing amplified system
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
Note: All chimes will be lost when using this harness
