3
REV. 8/26/2025 INSTAXTO-VW1
With the key in the off position:
•
Connect the 16-pin harness with stripped leads, and the AXTO-VW1 harness, into the interface
.
• If an AXSWC (sold separately) will be used, do not connect it until the AXTO-VW1 is
programmed and fully functional.
Attention! Do not connect the AXTO-VW1 harness to the wiring harness in the vehicle just yet.
For the steps below, the L.E.D. located inside the interface can only be seen while active. The
interface does not need to be opened to see the L.E.D.
1. Start the vehicle.
2. Connect the AXTO-VW1 harness to the wiring harness in the vehicle. The L.E.D. will initially be
Green to indicate the interface is powered.
3.
After a few seconds the L.E.D. will turn on solid Red while the interface automatically programs
to the vehicle. The radio will shut off at this point. This process should take 5 to 30 seconds
.
4. After the interface is programmed, the L.E.D. will turn on solid Green, and the radio will
come back on, indicating programming was successful.
5. Test all functions of the installation for proper operation, before reassembling the dash.
6. If the interface fails to function, refer to “Troubleshooting”.
Resetting the Axxess interface
1. The Blue reset button is located inside the Axxess interface, between the two connectors.
The button is accessible outside the Axxess interface, no need to open the Axxess interface.
2. Press and hold the reset button for two seconds, then let go to reset the Axxess interface.
3. Refer to “Programming the Axxess Interface” from this point.
Audio level adjustment
(Fender amplified systems only)
:
• With the vehicle and radio turned on, turn the volume up 3/4 of the way.
• With a small flat-blade screwdriver, adjust the potentiometer clockwise to raise the audio
level; counterclockwise to lower the audio level.
• Once at a desired level, audio level adjustment is complete.
INSTALLING THE AXTO-VW1
PROGRAMMING THE AXTO-VW1 TROUBLESHOOTING
ADJUSTING THE AXTO-VW1
