AXTC-CH1 3
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 3/28/23 INSTAXTC-CH13
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties
TABLE OF CONTENTS
Applications ...........................................................2
Connections
LDSWCX-6502 Without Amp ..............................3
LDSWCX-6502 With Amp ...................................4
LDSWCX-6522 Without Amp .............................. 5
LDSWCX-6522 With Amp .................................... 6
Programming .........................................................7
Troubleshooting.....................................................8
APPLICATIONS
• AXTC-CH13 interface • LD-SWCX-6502 harness • LD-SWCX-6522 harness • 3.5mm adapter
See inside front cover
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections, especially the air
bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket accessory before
installing this device.
Provides accessory power (10-amp)
Provides wires for multimedia
radios (park brake, reverse,
speed sense)
Retains audio controls on the
steering wheel
Can be used in both amplified
and non-amplified models
Retains balance and fade (†)
Designed to be compatible
with all major radio brands
Auto detects vehicle type, radio
connection, and preset controls
Ability to dual assign steering
wheel control buttons
Retains memory settings even
after battery disconnection or
interface removal (non volatile
memory)
Provides illumination output
Micro-B USB updatable
(†) Non-amplified models only
INTERFACE FEATURES
Provides accessory power (10-amp)
Provides wires for multimedia
radios (park brake, reverse,
speed sense)
Retains audio controls on the
steering wheel
Can be used in both amplified
and non-amplified models
Retains balance and fade (†)
Designed to be compatible
with all major radio brands
Auto detects vehicle type, radio
connection, and preset controls
Ability to dual assign steering
wheel control buttons
Retains memory settings even
after battery disconnection or
interface removal (non volatile
memory)
Provides illumination output
Micro-B USB updatable
(†) Non-amplified models only
Chrysler SWC (Steering Wheel Control)
and Data Interface 2004-Up
