CONNECTIONS TO BE MADE
Into the vehicle
With the key in the off position:
1. Connect the Black wire of the AXSWC-TL to ground.
2. Connect the (2) Red wires of the AXSWC-TL to accessory power.
3. For all vehicles EXCEPT the Lexus SC430, connect ONLY the 12-pin connector to the
mating connector in the vehicle. The 6-pin connector on the AXSWC-TL harness WILL
NOT be used in the application.
4. For the 2002-2005 Lexus SC430, connect ONLY the 6-pin connector to the mating
connector in the vehicle. The 12-pin connector on the AXSWC-TL harness WILL NOT
be used in the application.
Note:
Disregard the 12-pin connector in the vehicle.
5. For the 2006-2009 Lexus SC430, connect BOTH the 6-pin and 12-pin connectors to
the mating connectors in the vehicle.
To the radio
1. For the radios below, connect the included female 3.5mm connector with the Brown
and Brown/White wires into the male 3.5mm connector of the AXSWC-TL harness.
•
For Eclipse radios: Connect the Eclipse steering wheel control wires (normally
Brown and Brown/Black) to the Brown and Brown/White wires of the AXSWC-TL.
Brown of the AXSWC-TL goes to the Brown/Black of the Eclipse and Brown/White
of the AXSWC-TL goes to the Brown of the Eclipse.
•
For Metra OE:
Connect the SWC Key 1 wire
(Gray)
to the
Brown
wire of the
AXSWC-TL. Isolate and tape the
Brown/White
wire, it will not be used.
•
For Kenwood or select JVC’s
with a
Blue/Yellow
steering wheel control wire
:
Connect the Kenwood/JVC steering wheel control wire to the
Brown
wire of the
AXSWC-TL. Isolate and tape the
Brown/White
wire, it will not be used.
Note:
Some of the newer Kenwood radios will auto detect as a JVC. If this is
the case, use a 12k ohm resistor in line between the Blue/Yellow and Brown
wire of the female 3.5mm jack during programming only (remove resistor once
programmed).
2. For Parrot Asteroid Smart or Tablet: Connect the AXSWC-TL male 3.5mm jack into
the AXSWCH-PAR (sold separately) female 3.5mm jack and plug the 4-pin end into
the corresponding SWC plug on the radio.
Note:
AXSWCH-PAR required (sold separately) and radio MUST BE updated to rev
2.1.4 or higher.
3. For XITE radios: Connect the steering wheel control SWC-2 wire from the radio to
the Brown wire of the AXSWC-TL.
4. For all other radios: Connect the 3.5mm jack of the AXSWC-TL into the jack on the
aftermarket radio designated for an external steering wheel control interface.
Please refer to the aftermarket radios manual if in doubt as to where the 3.5mm
jack goes into.
