AXRSEH -GL29 AXRSEH -GL29 AXRSEH -GL29

INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS

REV. 4/20/20 REV. 4/20/20 REV. 4/20/20

Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com

• Retains the A/V-IN jack (if applicable)

• Provides A/V output to the factory installed rear seat overhead

entertainment system *

• Designed for models that have a DVD player built into the factory radio

• Retains the A/V-IN jack (if applicable)

• Provides A/V output to the factory installed rear seat overhead

entertainment system *

• Designed for models that have a DVD player built into the factory radio

• Retains the A/V-IN jack (if applicable)

• Provides A/V output to the factory installed rear seat overhead

entertainment system *

• Designed for models that have a DVD player built into the factory radio

INTERFACE FEATURES INTERFACE FEATURES INTERFACE FEATURES

• Wire cutter • Crimping tool

• Connectors (example: butt-connectors, bell caps, etc.)

• Wire cutter • Crimping tool

• Connectors (example: butt-connectors, bell caps, etc.)

• Wire cutter • Crimping tool

• Connectors (example: butt-connectors, bell caps, etc.)

TOOLS REQUIRED TOOLS REQUIRED TOOLS REQUIRED

GM RSE A/V Harness 2007-Up GM RSE A/V Harness 2007-Up GM RSE A/V Harness 2007-Up

APPLICATIONS APPLICATIONS APPLICATIONS

• AXRSEH-GL29 harness • AXRSEH-GL29 harness • AXRSEH-GL29 harness

• Connect to the AXRSEH-GL29 harness to the wiring harness in the

vehicle located at the radio location.

• Connect to the AXRSEH-GL29 harness to the wiring harness in the

vehicle located at the radio location.

• Connect to the AXRSEH-GL29 harness to the wiring harness in the

vehicle located at the radio location.

INTERFACE COMPONENTS INTERFACE COMPONENTS INTERFACE COMPONENTS

CONNECTIONS TO BE MADE CONNECTIONS TO BE MADE CONNECTIONS TO BE MADE

INSTALLATION INSTALLATION INSTALLATION

BUICK

Enclave 2008-Up

Cadillac

Escalade 2007-2011

Escalade ESV 2007-2011

Escalade EXT 2007-2011

SRX 2007-2009

CHEVROLET

Avalanche ∆ 2007-2013

Equinox 2007-2009

Silverado 2500/3500 ∆ 2014

Silverado (new body) ∆ 2007-2013

Suburban ∆ 2007-2014

Tahoe ∆ 2007-2014

Traverse 2009-Up

GMC

Acadia 2007-2016

Acadia Limited 2017

Sierra 2500/3500 ∆ 2014

Sierra (new body) ∆ 2007-2013

Yukon/Yukon XL ∆ 2007-2014

HUMMER

H2 2008-2009

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

SUZUKI

XL-7 2007-2009

BUICK

Enclave 2008-Up

Cadillac

Escalade 2007-2011

Escalade ESV 2007-2011

Escalade EXT 2007-2011

SRX 2007-2009

CHEVROLET

Avalanche ∆ 2007-2013

Equinox 2007-2009

Silverado 2500/3500 ∆ 2014

Silverado (new body) ∆ 2007-2013

Suburban ∆ 2007-2014

Tahoe ∆ 2007-2014

Traverse 2009-Up

GMC

Acadia 2007-2016

Acadia Limited 2017

Sierra 2500/3500 ∆ 2014

Sierra (new body) ∆ 2007-2013

Yukon/Yukon XL ∆ 2007-2014

HUMMER

H2 2008-2009

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

SUZUKI

XL-7 2007-2009

BUICK

Enclave 2008-Up

Cadillac

Escalade 2007-2011

Escalade ESV 2007-2011

Escalade EXT 2007-2011

SRX 2007-2009

CHEVROLET

Avalanche ∆ 2007-2013

Equinox 2007-2009

Silverado 2500/3500 ∆ 2014

Silverado (new body) ∆ 2007-2013

Suburban ∆ 2007-2014

Tahoe ∆ 2007-2014

Traverse 2009-Up

GMC

Acadia 2007-2016

Acadia Limited 2017

Sierra 2500/3500 ∆ 2014

Sierra (new body) ∆ 2007-2013

Yukon/Yukon XL ∆ 2007-2014

HUMMER

H2 2008-2009

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

SUZUKI

XL-7 2007-2009

* Only applicable for models with a second row RSE * Only applicable for models with a second row RSE * Only applicable for models with a second row RSE

∆ For 2012-Up models with NAV use the AXRSEH-G2. ∆ For 2012-Up models with NAV use the AXRSEH-G2. ∆ For 2012-Up models with NAV use the AXRSEH-G2.

•

Connect the Black wire with a ring terminal to the chassis of the aftermarket radio

• From the RCA jacks labeled “FROM REAR A/V INPUT” to the A/V input of the

aftermarket radio:

• Connect the Yellow RCA jack to the video in.

• Connect the Red and White RCA jacks to the audio in.

• From the RCA jacks labeled “TO OVERHEAD SCREEN” to the A/V output of the

aftermarket radio:

• Connect the Yellow RCA jack to the video out.

• Connect the Red and White RCA jacks to the audio out.

•

Connect the Black wire with a ring terminal to the chassis of the aftermarket radio

• From the RCA jacks labeled “FROM REAR A/V INPUT” to the A/V input of the

aftermarket radio:

• Connect the Yellow RCA jack to the video in.

• Connect the Red and White RCA jacks to the audio in.

• From the RCA jacks labeled “TO OVERHEAD SCREEN” to the A/V output of the

aftermarket radio:

• Connect the Yellow RCA jack to the video out.

• Connect the Red and White RCA jacks to the audio out.

•

Connect the Black wire with a ring terminal to the chassis of the aftermarket radio

• From the RCA jacks labeled “FROM REAR A/V INPUT” to the A/V input of the

aftermarket radio:

• Connect the Yellow RCA jack to the video in.

• Connect the Red and White RCA jacks to the audio in.

• From the RCA jacks labeled “TO OVERHEAD SCREEN” to the A/V output of the

aftermarket radio:

• Connect the Yellow RCA jack to the video out.

• Connect the Red and White RCA jacks to the audio out.
