386.257.1187
|
MetraOnline.com
4
(Figure E) (Figure G)
(Figure F)
DASH DISASSEMBLY (CONT.)
4. Unclip and remove the top of the
console including the cup holders
and shifter. (Figure E)
Note: Start at the front of the console.
There are hooks on trim panel so be
careful when removing.
5. Unclip and let the left side of the knee
bolster panel hang then remove (2)
7mm exposed on right side of panel.
(Figure F)
6. Remove the screw cover on the driver’s
side center console panel then remove
the (1) 7mm screw exposed. (Figure G)
7. Unclip and remove the console side trim
panel. (Figure G)
8. Unclip and remove the console side trim
panel from the passenger side.
(Figure H)
Continued on the next page
(Figure H)
