REV. 7/25/24 INSTAXPIO-COL2
EXTERNAL SPEAKER
LD-AX-SPK
Pioneer Harness
LD-GM30-PIO
CARSIDE CONNECTORS (CONNECT TO
EXTENSION)
MICRO-HDMI
ADAPTER NEEDED
(N/A)
EXT SPKR
CAN 2
CAN3
“TBA” WIRES
AD-EU5
AUX IN
High-Level
PRO4-AVIC-PIO
USB/AUX
(USE INSTEAD)
AXXESS INTERFACE
PRO4-PIORCA
Low-Level
AUX (INCL. W/RADIO)
GPS
4-PIN MIC HDMI
ANT
18P (M)
18P (F)
16P 22P
40-GPS-PIO
10
TBA
CONNECTIONS
Important: Verify HVAC status & control, Steering
wheel audio controls, and External Speaker output
prior to completing dash assembly.
Important: Install the provided
speaker in the dash prior to assembling
the radio components.
Note: Make sure this is mounted in a
location suitable for the driver to hear.
(Audio level for the speaker can be
changed via the radio, once installed.)
Note: LD-GM30-PIO applications will
not retain the factory backup camera.
