Je bekijkt pagina 3 van 4
3
REV. 1/22/2020 INSTAXHN-1
With the key in the off position:
• Connect the 16-pin harness with stripped leads, and the AXHN-1 harness, into the interface.
• If an AXSWC (sold separately) will be used, do not connect it until the AXHN-1 is programmed
and fully functional.
Attention! Do not connect the AXHN-1 harness to the wiring harness in the vehicle just yet.
For the steps below, the L.E.D. located inside the interface can only be seen while active. The
interface does not need to be opened to see the L.E.D.
1. Start the vehicle.
2. Connect the AXHN-1 harness to the wiring harness in the vehicle. The L.E.D. will initially be
Green to indicate the interface is powered.
3. After a few seconds the L.E.D. will turn on solid Red while the interface automatically
programs to the vehicle. The radio will shut off at this point. This process should take 5 to 30
seconds.
4. After the interface is programmed, the L.E.D. will turn on solid Green, and the radio will
come back on, indicating programming was successful.
5. Test all functions of the installation for proper operation, before reassembling the dash.
6. If the interface fails to function, refer to “Troubleshooting”.
Resetting the Axxess interface
1. The Blue reset button is located inside the Axxess interface, between the two connectors.
The button is accessible outside the Axxess interface, no need to open the Axxess interface.
2. Press and hold the reset button for two seconds, then let go to reset the Axxess interface.
3. Refer to “Programming the Axxess Interface” from this point.
The buttons on the steering wheel will be used to set the factory clock.
• Press and hold the SOURCE button on the steering wheel for 15 seconds to access the clock
setting mode.
• Press SEEK-UP or SEEK-DOWN to select hours, minutes, etc. Press VOLUME-UP or
VOLUME-DOWN to set the values.
•
Either press SOURCE again, or wait 5 seconds with no activity to exit the clock setting mode
.
INSTALLING THE AXHN-1
PROGRAMMING THE AXHN-1 TROUBLESHOOTING
SETTING THE FACTORY CLOCK
