2
Adding a sub to a factory system:
This feature offers the ability to add a subwoofer to a factory system. (Refer to Page 3)
Adding a full-range amp & sub to a factory system:
This feature offers the ability to add a full-range amp and sub to a factory system. (Refer to Page 4)
Note: The interface provides a 12-volt 1-amp output to turn on aftermarket amp(s). If installing
multiple amps, an SPDT automotive relay will be required if the amp turn-on current of all amps
combined exceeds 1-amp. Use Metra part number E-123 (sold separately) for best results.
1. Remove the factory radio*, then unplug all connectors.
2. Install the AXDSPX-VW2 vehicle T-harness to the vehicle and make all necessary
connections, but leave the amp turn-on wire disconnected.
3. Plug the AXDSPX-VW2 vehicle T-harness to the AXDSPX-VW2 interface.
4. Plug the AXDSPX-VW2 interface harness to the AXDSPX-VW2 interface.
5.
Download and install the
AX-DSP-XL app for your smart device.
6. Open the app then select the Bluetooth Connection tab. Follow the instructions to
pair the mobile device to the interface. Refer to Page 5 for more information.
7. Scroll to the Configuration tab then select the vehicle type. Press the Lock Down**
button to save the configuration. Refer to Page 6 for more information.
8. Connect the amp turn-on wire.
9. Adjust the settings in the app as desired. Press the Lock Down** button to save any
new configurations.
* For dash disassembly instructions, refer to metraonline.com Enter the year, make,
and model of the vehicle in the Vehicle Fit Guide and find instructions under
Metra Radio Install kits.
** Anytime the interface is locked down the key must be cycled off then back on.
INSTALLATION OPTIONS I N S TALLATIO N
