3
REV. 5/9/25 INSTAXDSPX-HK2
1. Locate the factory amp, unplug all connectors, then remove the amp.
Note: Amp location is on the previous page.
2. Install the AXDSPX-HK2 harness and make all necessary connections, but leave the amp
turn-on wire disconnected.
3. Plug the 16-pin and 20-pin connectors from the AXDSPX-HK2 harness into the AXDSP-X.
4. Download and install the AX-DSP-XL app for your smart device.
5. Open the app and follow the instructions on the Bluetooth Connection tab to pair the
mobile device to the AXDSP-X. (Figure A)
6. Scroll to the Configuration tab then select the vehicle type. Press the Lock Down button to
save the configuration. (Figure B)
7.
Connect the amp turn-on wire from the AXDSPX-HK2 harness. Click the Identify button to
confirm that the AXDSPX-HK2 is connected properly. If so, a chime will be heard from the
front left speaker. Test all functions of the installation for proper operation
.
Note: The outputs may need to be configured within the Outputs tab.
8.
Adjust the DSP settings in the app as desired. Refer to the instructions under the Setup
Instructions tab, or online at Axxessinterfaces.com for an explanation of each tab in the app.
I N STALL ATI O N
Continued on the next page
(Figure A)
(Figure B)
