2
Adding a subwoofer to a factory system:
This feature offers the ability to add a subwoofer to a factory system, whether amplified or non-
amplified (Refer to Page 3)
Adding a full-range amp and subwoofer to a factory system:
This feature offers the ability to add a full-range amp and sub to a factory system, whether amplified*
or non-amplified. (Refer to Page 4)
*
For amplified models the amp must be bypassed/unplugged, and With OE Amplifier chosen in the
Configuration tab under Vehicle Type.
Note: The interface provides a 12-volt 1-amp output to turn on aftermarket amp(s). If installing
multiple amps, an SPDT automotive relay will be required if the amp turn-on current of all amps
combined exceeds 1-amp. Use Metra part number E-123 (sold separately) for best results.
1. Remove the factory radio*, then unplug all connectors.
2. Install the AX-DSPX-FD1 vehicle T-harness to the vehicle and make all necessary
connections, but leave the amp turn-on wire disconnected.
3. Plug the AX-DSPX-FD1 vehicle T-harness to the AX-DSPX-FD1 interface.
4. Plug the AX-DSPX-FD1 interface harness to the AX-DSPX-FD1 interface.
5. Download and install the AXDSP-X app from the Google Play Store or Apple App Store.
6. Open the app then select the Bluetooth
®
Connection tab. Follow the instructions to pair
the mobile device to the interface. Refer to Page 5 for more information.
7. Scroll to the Configuration tab then select the vehicle type. Press the Lock Down **
button to save the configuration. Refer to Page 6 for more information.
8. Connect the amp turn-on wire.
9. Adjust the settings in the app as desired. Press the Lock Down ** button to save any
new configurations.
* Refer to metraonline.com for dash disassembly. If Metra makes a dash kit for the
vehicle, disassembly will be within those instructions.
** Anytime the interface is locked down the key must be cycled off then back on.
INSTALLATION OPTIONS I NSTALL AT I O N
• Easy behind the radio installation with pre-wired harness
• Bass knob included for level control of subwoofer amp
• Settings adjusted via Bluetooth
®
in a smart device application (tablet or mobile phone), compatible
with both Android and Apple devices
• Read, write, and store configurations for future recall
• Password protect feature available in the mobile app
• Micro-B USB updatable
FEATURES CO NT.
