INSTALLATION INSTRUCTIONS

INTERFACE COMPONENTS

ETHERNET DSPX PACKAGE

Fits GENERAL MOTORS 2019-UP

• AXDSPX-ETH1 interface

• AXDSPX-ETH1 harness

• LD-DSP-ETH1

• LD-DSP-ETH2

For Dash Disassembly Instructions, refer to metraonline.com. Enter the year, make, and model of the vehicle in the Vehicle Fit Guide for Radio Install kits.

Visit

axxessinterfaces.com

for current application list.

TABLE OF CONTENTS

Interface Features ..................................................2

Connections: Adding A Full-Range Amp &

Sub To A Factory System ..............................3-4

Installation ..............................................................5

Quick Setup Steps: AX-DSP-XL App ...................... 6

Specifications .........................................................7

Troubleshooting..................................................... 8

LED Feedback ......................................................... 8

Speaker Assignment QR Code .............................. 8

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

Visit AxxessInterfaces.com for more detailed information

about the product and up-to-date vehicle specific applications

• AXBK-1

• LD-ETH-ADAPT harness

• Amplifier bypass harness (female

connectors: 8-pin black, 20-pin green )

ATTENTION: With the key out of the

ignition, disconnect the negative battery

terminal before installing this product.

Ensure that all installation connections,

especially the air bag indicator lights, are

plugged in before reconnecting the battery

or cycling the ignition to test this product.

NOTE: Refer also to the instructions included

with the aftermarket accessory before

installing this device.

Apple App Store

iOS 12.1 or higher

www.MetraOnline.com

Google Play Store

Android 9 or higher

For Dash Disassembly Instructions, refer to

metraonline.com. Enter the year, make, and

model of the vehicle in the Vehicle Fit Guide

for Radio Install kits.
