INSTALLATION INSTRUCTIONS

INTERFACE COMPONENTS

Ford Select Models 2018-Up* A2B Data Interface

with Amplifier Bypass Harness & DSP

• AXDSPX-A2B2 interface

• AXDSPX-A2B2 harness

• Amplifier bypass harness

• Radio T-Harness

• AXBK-1

• A2B-EXT

• Bass Knob

• Extension Cable

For Dash Disassembly Instructions, refer to metraonline.com. Enter the year, make, and model of the vehicle in the Vehicle Fit Guide for Radio Install kits.

*Visit axxessinterfaces.com for current application list.

TABLE OF CONTENTS

Interface Features ..................................................2

Things To Know About The AXDSP ...................3-4

Connections ........................................................5-6

Quick Setup Steps: AXDSP-XL App .......................7

LED Feedback .........................................................8

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun, solder, and heat shrink

• Tape

• Wire cutter

• Zip-ties

Google Play Store

Apple App Store

iOS 12.1 or higher

ATTENTION: With the key out of the ignition,

disconnect the negative battery terminal before

installing this product. Ensure that all installation

connections, especially the air bag indicator lights,

are plugged in before reconnecting the battery or

cycling the ignition to test this product.

NOTE: Refer also to the instructions included with

the aftermarket radio.

Metraonline.com

Visit MetraOnline.com and Axxessinterfaces.com for harness and interface options.
