LED Feedback Legend: The (24) Red LED flashes

represent a different radio manufacturer for the

SWC interface to detect. For example, if you are

installing a JVC radio, the SWC interface will flash

Red (5) times, then stop. Following is the LED

Feedback Legend, which indicates the flash count

of the radio manufacturer.

Flash Count

Radio

Eclipse (type 1) †

Kenwood ‡

Clarion (type 1) †

Sony / Dual

JVC

Pioneer / Jensen

Alpine *

Visteon

Valor

Clarion (type 2) †

Metra OE

Eclipse (type 2) †

Flash Count

Radio

Parrot **

XITE

Philips

TBA

JBL

Insane

Magnadyne

Boss

Axxera

Axxerra (type 2)

Alpine (type 2)

LED Feedback Legend

STEERING WHEEL CONTROL SETTINGS

KEYNOTES

* If the SWC interface flashes Red (7) times, and an Alpine radio is not installed, that means there is an open connection not accounted for. Verify that the 3.5mm jack is connected to the correct steering wheel jack/

wire in the radio.

The AXSWCH-PAR is required (sold separately). Also, the software in the radio must be rev. 2.1.4 or higher.

† If a Clarion or Eclipse radio is installed and the steering wheel controls do not function, change the radio

to Clarion (type 2) or Eclipse (type 2) respectively. If the steering wheel controls still do not function, refer to

the Changing Radio Type document available at axxessinterfaces.com.

‡ If a Kenwood radio is installed and the LED feedback flashes (5) times instead of (2), manually change the radio

type to Kenwood. To do this, refer to the Changing Radio Type on next page.
