AXDIS-MZ1
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 11/22/24 INSTAXDIS-MZ1
INTERFACE FEATURES
INTERFACE COMPONENTS TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
TABLE OF CONTENTS
Connections ........................................................2-4
For models
without
an amplifier ....................... 2
For models
with
an amplifier.............................3
3.5mm jack steering wheel control retention .. 4
Installing the AXDIS-MZ1 .......................................4
Programming the AXDIS-MZ1 ............................... 5
Steering wheel control (SWC) settings............5-8
LED feedback ....................................................... 5
Changing radio type ........................................... 6
Remapping the (SWC) buttons ..........................6-7
Dual assignment instructions ....................................7-8
Troubleshooting.....................................................8
Fits Mazda Data Interface with SWC 2007-2015
APPLICATIONS
• Designed for both amplified and non-amplified models
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains balance and fade (excludes amplified models)
• Retains the ability to set the clock with a service harness
• Micro-B USB updatable
MAZDA
CX-7 .............................................................................................2007-2012
CX-9 .............................................................................................2007-2010
CX-9 ..............................................................................................2013-2015
• AXDIS-MZ1 interface
• AXDIS-MZ1 harness
• 16-pin harness with stripped leads
• Female 3.5mm connector with stripped leads
MetraOnline.com may be used
to assist with dash assembly
instructions. Simply enter your
Year, Make, Model vehicle into
the vehicle fit guide and look
for the Dash Kit Installation
Instructions.
Product Info
www.MetraOnline.com
ATTENTION: With the key out of the ignition,
disconnect
the negative battery terminal before installing
this product. Ensure that all installation connections,
especially the air bag indicator lights, are plugged in
before reconnecting the
battery or cycling the ignition to
test this product.
NOTE: Refer also to the instructions included with the
aftermarket accessory before installing this device.
Visit AxxessInterfaces.com for more detailed information
about the product and up-to-date vehicle specific applications.
