REV. 11/22/24 INSTAXDIS-HK4

LED Feedback: The (24) Red LED flashes

represent a different radio manufacturer for

the AXDIS-HK4 interface to detect.

For example, if you are installing a JVC radio,

the AXDIS-HK4 interface will flash Red (5)

times, then stop.

At right is the LED Feedback Legend,

that indicates

which radio Manufacturer

corresponds to which flash.

Flash Count

Radio

Eclipse (type 1) †

Kenwood ‡

Clarion (type 1) †

Sony / Dual

JVC

Pioneer / Jensen

Alpine *

Visteon

Valor

Clarion (type 2) †

Metra OE

Eclipse (type 2) †

Flash Count

Radio

Parrot **

XITE

Philips

TBD

JBL

Insane

Magnadyne

Boss

Axxera

Axxerra (type 2)

Alpine (type 2)

LED Feedback Legend

STEERING WHEEL CONTROL SETTINGS

KEYNOTES

*If the AXDIS-HK4 flashes RED (7) times, and an Alpine radio is not installed, that means there is an open connection not accounted for. Verify that the 3.5mm jack is connected to the correct steering

wheel jack/wire in the radio.

** The AXSWCH-PAR is required (sold separately). Also, the software in the radio must be rev. 2.1.4 or higher.

† If a Clarion or Eclipse radio is installed and the steering wheel controls do not function, change the radio to Clarion (type 2) or Eclipse (type 2) respectively. If the steering wheel controls still do not

function, refer to the Changing Radio Type document available at axxessinterfaces.com.

‡ If a Kenwood radio is installed and the LED feedback flashes (5) times instead of (2), manually change the radio type to Kenwood. To do this, refer to the Changing Radio Type document on next

page, also available at axxessinterfaces.com.

Continued on the next page
