2
CONNECTIONS
From the 16-pin Harness with Stripped Leads to the Aftermarket Radio:
• Connect the Red wire to the accessory wire.
• Connect the Blue/White wire to the amp turn-on wire.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
The following (1) wire is only for a multimedia/navigation radio that requires this wire.
• Connect the Light Green wire to the parking brake wire.
• Tape off and disregard the following (8) wires, they will not be used in this application:
Blue/Pink, Brown, Green, Green/Black, Green/Purple, Orange/White, Purple, Purple/Black
From the AXDIS-HK4 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Blue wire to the power antenna wire.
• If the aftermarket radio has an illumination wire, connect the Orange wire to it.
The following (2) wires are only for a multimedia/navigation radio that requires these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• If the factory AUX-IN jack is desired to be retained, connect the Red & White RCA jacks to
the audio AUX-IN jacks.
• Connect the Yellow RCA jack to the backup camera input.
