6
STEERING WHEEL CONTROL SETTINGS
(CONT.)
Remapping the steering wheel control buttons
Once the AXDIS-HK3 interface has been programmed, the button assignment for the steering
wheel controls may be reassigned if so desired. For example, if Seek Up is preferred to be Mute
instead. Follow the steps below to remap the steering wheel control buttons.
1. Ensure that the AXDIS-HK3 interface is visible so you can see the LED flashes to confirm
button recognition.
Tip: Turning the radio off is recommended.
2. Within the first twenty seconds of turning the ignition on, press and hold the Volume Up
button on the steering wheel until the LED goes solid.
3. Release the Volume Up button, the LED will then go out. The Volume Up button has now
been programmed.
4. Follow the list in the Button Function Legend to reference the order in which the steering
wheel control buttons need to be programmed.
Note: If the next function on the list is not present on the steering wheel, press the Volume
Up button for (1) second until the LED comes on to skip that function, then release the
Volume Up button. This will tell the AXDIS-HK3 interface that this function is not available,
and to move on to the next function.
5. To complete the remapping process, press and hold the Volume Up button until the LED in
the AXDIS-HK3 interface goes out.
Continued on the next page
Changing radio type: If the LED flashes do not match the radio you have connected, you must
manually program the AXDIS-HK3 interface to tell it what radio it is connected to.
1. After (3) seconds of turning the key on, press and hold the Volume Down button on the
steering wheel until the LED in the AXDIS-HK3 interface goes solid.
2. Release the Volume Down button; the LED will go out indicating the AXDIS-HK3 interface is
in Changing Radio Type mode.
3. Refer to the Radio Legend to know which radio number you would like to have programmed.
4. Press and hold the Volume Up button until the LED goes solid, then release. Repeat this step
for the desired radio number you have selected.
5. Once the desired radio number has been selected, press and hold the Volume Down button
on the steering wheel until the LED goes solid. The LED will remain on for about (3) seconds
while it stores the new radio information.
Attention:
The Axxess Updater App can also be used to program the following (3) sub-sections
as well, pending that the AXDIS-HK3 interface has been programmed and is functional
.
Flash Count Radio Legend
1. Eclipse (type 1)
2. Kenwood
3. Clarion (type 1)
4. Sony / Dual
5. JVC
6. Pioneer / Jensen
7. Alpine
8. Visteon
9. Valor
10. Clarion (type 2)
11. Metra OE
12. Eclipse (type 2)
13. LG
14. Parrot
15. XITE
16. Philips
17. TBD
18. JBL
19. Insane
20. Magnadyne
21. Boss
22. Axxera
23. Axxerra (type 2)
24. Alpine (type 2)
6. Once the LED goes
out, the Changing
Radio Type mode
will then end. You
can now test the
steering control
wheel controls.
Note: If at any time
the user fails to press
any button for a period
longer than (10) seconds,
this process will abort.
