CONNECTIONSAPPLICATIONS

From the 16-pin harness with stripped leads to the aftermarket radio:

• Connect the Red wire to the accessory wire.

• If the vehicle comes equipped with a factory amplifier, connect the Blue/White wire to the

amp turn-on wire.

• Connect the Gray wire to the right front positive speaker output.

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the White wire to the left front positive speaker output.

• Connect the White/Black wire to the left front negative speaker output.

• Connect the Green/Purple wire to the reverse wire, and also to the Blue/White wire from

the AXCSD-6V.

The following (1) wire is only for a multimedia/navigation radio that requires this wire.

• Connect the Light Green wire to the parking brake wire.

• Tape off and disregard the following (8) wires, they will not be used in this application:

Blue/Pink, Blue/White*, Brown, Green, Green/Black, Orange/White, Purple, Purple/Black

* Non-amplified models only

From the AXDIS-HK3 harness to the aftermarket radio:

• Connect the Black wire, the Black wire labeled “Camera Ground”, and also the Black wire

from the AXCSD-6V, to the ground wire.

•

Connect the Red wire labeled “Camera Power 6V”, to the Blue/Red wire from the AXCSD-6V

• Connect the Yellow wire to the battery wire.

• Connect the Blue wire to the power antenna wire.

• If the aftermarket radio has an illumination wire, connect the Orange wire to it.

Hyundai

Accent (7” Touchscreen) ......................................................................................................2018-2019

Elantra (7” Touchscreen) .....................................................................................................2019-2020

Elantra (7” Touchscreen Non-NAV) ..................................................................................... 2017-2018

Elantra GT ....................................................................................................................................... 2018

Ioniq (Non-NAV) ................................................................................................................... 2018-2019

Kona .......................................................................................................................................2018-2022

Santa Fe/Sport ............................................................................................................................... 2019

Sonata (w/NAV) ............................................................................................................................. 2018

Sonata (7” Touchscreen Non-NAV) ...............................................................................................2017

Veloster (Non-NAV) ........................................................................................................................2017

Kia

Forte ................................................................................................................................................ 2019

Forte / Forte 5 (7” Touchscreen Non-NAV) ......................................................................... 2017-2018

Optima (Non-NAV Manual Climate Screen) ................................................................................ 2019

Rio / Rio 5 (7” Touchscreen) ......................................................................................................... 2018

Sedona (7” Touchscreen Non-NAV) .................................................................................... 2017-2018

Seltos .............................................................................................................................................. 2021

Sorento (7” Touchscreen Non-NAV) ............................................................................................ 2019

Continued on the next page
