9
REV. 11/1/24 INSTAXDIS-GMLN44
Changing Radio Type
If the LED flashes do not match the radio you have connected, you must manually
program the AXDIS-GMLN44 to tell it what radio it is connected to.
1. After (3) seconds of turning the key on, press and hold the Volume-Down button on the
steering wheel until the LED in the AXDIS-GMLN44 goes solid.
2. Release the Volume-Down button; the LED will go out indicating we are now in
Changing Radio Type mode.
3. Refer to the Radio Legend to know which radio number you would like to have
programmed.
4. Press and hold the Volume-Up button until the LED goes solid, and then release. Repeat
this step for the desired radio number you have selected.
5. Once the desired radio number has been selected, press and hold the Volume-Down
button on the steering wheel until the LED goes solid. The LED will remain on for about
(3) seconds while it stores the new radio information.
6. Once the LED goes off, the Changing Radio Type mode will then end. You can now test
the steering control wheel controls.
Note:
If at any time the user fails to press any button for a period longer than (10)
seconds, this process will abort.
Attention:
The Axxess Updater App can also be used to program the following (3) sub-sections
as well, pending that the interface has been initialized and programmed.
STEERING WHEEL CONTROL SETTINGS (CONT)
Remapping the Steering Wheel Control Buttons
Flash Count Radio Legend
1. Eclipse (type 1)
2. Kenwood
3. Clarion (type 1)
4. Sony / Dual
5. JVC
6. Pioneer / Jensen
7. Alpine
8. Visteon
9. Valor
10. Clarion (type 2)
11. Metra OE
12. Eclipse (type 2)
13. LG
14. Parrot
15. XITE
16. Philips
17. TBD
18. JBL
19. Insane
20. Magnadyne
21. Boss
22. Axxera
23. Axxerra (type 2)
24. Alpine (type 2)
Let’s say you have
AXDIS-GMLN44 initialized
and you want to change
the button assignment
for the steering wheel
control buttons. For
example, you would
like Seek-Up to become
Mute. Follow the steps
below to remap the
steering wheel control
buttons:
1. Ensure the AXDIS-GMLN44 is visible so you can see the LED flashes to confirm button recognition.
Tip:
Turning the radio off is recommended.
2. Within the first twenty seconds of turning the ignition on, press and hold the Volume-Up button on
the steering wheel until the LED goes solid.
3. Release the Volume-Up button, the LED will then go out; The Volume-Up button has now been
programmed.
4. Follow the list in the Button Assignment Legend to reference the order in which the steering wheel
control buttons need to be programmed.
Note:
If the next function on the list is not on the steering wheel, press the Volume-Up button for (1)
second until the LED comes on, and then release the Volume-Up button. This will tell the AXDIS-GMLN44
that this function is not available and it will move on to the next function.
5. To complete the remapping process, press and hold the Volume-Up button on the steering wheel
until the LED in the AXDIS-GMLN44 goes out.
Continued on the next page
