PROGRAMMING THE AXDIS-GMLN31
For the steps below, the LED located inside the interface can only be seen while active. The
interface does not need to be opened to see the LED
1. Start the vehicle.
2. Connect the AXDIS-GMLN31 harness to the wiring harness in the vehicle.
3. The LED will initially turn on solid Green, then turn off for a few seconds while it auto
detects the radio installed.
4.
The LED will then flash Red up to (24) times indicating which radio is connected to the
interface, and then turn off for a couple of seconds. Pay close attention to how many Red
flashes there are. This will help in troubleshooting, if need be. Refer to the LED Feedback
section for more information.
5. After a couple seconds the LED will turn on solid Red while the interface auto detects the
vehicle. The radio will shut off at this point. This process should take 5 to 30 seconds.
6. Once the vehicle has been auto detected by the interface, the LED will turn on solid Green,
and the radio will come back on, indicating programming was successful.
7.
Test all functions of the installation for proper operation, before reassembling the dash.
If the interface fails to function, refer to Resetting the AXDIS-GMLN31.
Note:
The LED will turn on solid Green for a moment, and then turn off under normal
operation after the key has been cycled.
INSTALLING THE AXDIS-GMLN31
With the Key in the Off Position:
• Connect the 16-pin harness with stripped leads, and the AXDIS-GMLN31 harness, into the
interface.
Attention!
Do not connect the AXDIS-GMLN31 harness to the wiring harness in the vehicle just yet
.
Attention!
If retaining steering wheel controls, ensure that the jack/wire is connected to the
radio before proceeding. If this step is skipped, the interface will need to be reset for the steering
wheel controls to function.
