6
Remapping the Steering Wheel Control Buttons
Let’s say you have AXDIS-GMLN30 initialized and you want to change the button assignment
for the steering wheel control buttons. For example, you would like Seek-Up to become Mute.
Follow the steps below to remap the steering wheel control buttons:
1. Ensure the AXDIS-GMLN30 is visible so you can see the LED flashes to confirm button
recognition. Tip:
Turning the radio off is recommended.
2. Within the first twenty seconds of turning the ignition on, press and hold the Volume-Up
button on the steering wheel until the LED goes solid.
3. Release the Volume-Up button, the LED will then go out; The Volume-Up button has now
been programmed.
4. Follow the list in the Button Assignment Legend to reference the order in which the
steering wheel control buttons need to be programmed.
Flash Count Radio Legend
1. Eclipse (type 1)
2. Kenwood
3. Clarion (type 1)
4. Sony / Dual
5. JVC
6. Pioneer / Jensen
7. Alpine
8. Visteon
9. Valor
10. Clarion (type 2)
11. Metra OE
12. Eclipse (type 2)
13. LG
14. Parrot
15. XITE
16. Philips
17. TBD
18. JBL
19. Insane
20. Magnadyne
21. Boss
22. Axxera
23. Axxerra (type 2)
24. Alpine (type 2)
Changing Radio Type
If the LED flashes do not match the radio you have connected, you must manually program the
AXDIS-GMLN30 to tell it what radio it is connected to.
1. After (3) seconds of turning the key on, press and hold the Volume-Down button on the
steering wheel until the LED in the AXDIS-GMLN30 goes solid.
2. Release the Volume-Down button; the LED will go out indicating we are now in Changing
Radio Type mode.
3.
Refer to the Radio Legend to know which radio number you would like to have programmed.
4. Press and hold the Volume-Up button until the LED goes solid, and then release. Repeat this
step for the desired radio number you have selected.
5. Once the desired radio number has been selected, press and hold the Volume-Down button
on the steering wheel until the LED goes solid. The LED will remain on for about (3) seconds
while it stores the new radio information.
6. Once the LED goes off, the Changing Radio Type mode will then end. You can now test the
steering control wheel controls.
Note:
If at any time the user fails to press any button for a period longer than (10) seconds,
this process will abort.
Attention:
The Axxess Updater App can also be used to program the following (3) sub-sections as
well, pending that the interface has been initialized and programmed.
STEERING WHEEL CONTROL SETTINGS (CONT)
Continued on the next page
