11
REV. 11/1/24 INSTAXDIS-GMLN29
1. Volume-Up
2. Volume-Down
3. Seek-Up/Next
4. Seek-Down/Prev
5. Source/Mode
6. Mute
7. Preset-Up
8. Preset-Down
9. Power
10. Band
11. Play/Enter
12. PTT (Push to Talk) *
13. On-Hook *
14. Off-Hook *
15. Fan-Up *
16. Fan-Down *
17. Temp-Up *
18. Temp-Down *
Button Assignment Legend
* Not applicable in this application
Note: Not all radios will have all of these commands. Please refer to the manual provided with the
radio, or contact the radio manufacturer for specific commands recognized by that particular radio.
Dual Assignment Instructions (Long Button Press)
The AXDIS-GMLN29 has the capability to assign (2) functions to a single button, except Volume-Up
and
Volume-Down. Follow the steps below to program the button(s) to your liking.
Note:
Seek-Up and Seek-Down come pre-programmed as Preset-Up and Preset-Down for a
long button press.
1. Turn on the ignition but do not start the vehicle.
2. Press and hold down the steering wheel control button that you want to assign a long press
function to for about (10) seconds, or until the LED flashes rapidly. At this point release the
button; the LED will then go solid.
STEERING WHEEL CONTROL SETTINGS
(CONT)
3. Release the Volume-Up button, the LED will then go out; The Volume-Up button has
now been programmed.
4. Follow the list in the Button Assignment Legend to reference the order in which the
steering wheel control buttons need to be programmed.
Note:
If the next function on the list is not on the steering wheel, press the Volume-Up
button for (1) second until the LED comes on, and then release the Volume-Up button. This
will tell the AXDIS-GMLN29 that this function is not available and it will move on to the
next function.
5. To complete the remapping process, press and hold the Volume-Up button on the
steering wheel until the LED in the AXDIS-GMLN29 goes out.
1. Not allowed
2. Not allowed
3. Seek-Up/Next
4. Seek-Down/Prev
5. Mode/Source
6. ATT/Mute
7. Preset-Up
8. Preset-Down
9. Power
10. Band
11. Play/Enter
12. PTT
13. On-Hook
14. Off-Hook
15. Fan-Up *
16. Fan-Down *
17. Temp-Up *
18. Temp-Down *
* Not applicable in this application
Dual Assignment Legend
3.
Press and release the Volume-Up button the number of times corresponding to the new
button number selected. Refer to the Dual Assignment Legend. The LED will flash rapidly while
the Volume-Up button is being pressed, and then go back to a solid LED once released. Go to
the next step once the Volume-Up button has been pressed the desired number of times.
Continued on the next page
