AXDIS-GMLN29
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 11/1/24 INSTAXDIS-GMLN29
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape • Connectors (example:
butt-connectors, bell caps, etc.) • Small flat-blade screwdriver
TABLE OF CONTENTS
Connections to Be Made ....................................3-6
For models without an Amplifier ...................... 3
For models with an Analog Amplifier ................4
For models with a Digital Amplifier ................... 5
3.5mm Jack Steering Wheel Control Retention
....6
Installing the AXDIS-GMLN29 ................................ 6
Programming the AXDIS-GMLN29 ........................7
Adjustments the AXDIS-GMLN29 ..........................7
Extra Features ........................................................8
Steering Wheel Control Settings (SWC).......... 9-11
LED Feedback .......................................................9
Changing Radio Type ..........................................9
Remapping the
SWC
Buttons
..................................10
Dual Assignment Instructions....................... 11-12
Troubleshooting....................................................12
GM Data Interface with SWC 2006-Up
• Designed for non-amplified, or analog/digital amplified models
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (Retained Accessory Power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
•
Retains balance and fade (excluding digital amplified models)
•
Retains RSE (Rear Seat Entertainment)
• AXDIS-GMLN29 interface
• AXDIS-GMLN29 harness
• Female 3.5mm connector with stripped leads
• 16-pin harness with stripped leads
• RSE harness
• 4-pin to 4-pin resistor pad harness
• Backup camera harness • Antenna adapter
APPLICATIONS
See inside front cover
Product Info
www.MetraOnline.com
MetraOnline.com may be used
to assist with dash assembly
instructions. Simply enter
your Year, Make, Model
vehicle into the vehicle fit
guide and look for the Dash
Kit Installation Instructions.
Visit AxxessInterfaces.com for up-to-date vehicle specific applications.
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
• Retains chimes
• Retains OnStar
®
/ OE Bluetooth
• Adjustable OnStar
®
level
• Retains the factory AUX-IN jack
•
Retains the factory backup camera
• Retains SAT (Satellite Radio)
• Includes an antenna adapter
• Micro-B USB updatable
