4
If equipped with SYNC
®
:
• If the vehicle is equipped with SYNC
®
, the AXDIS-FD2 can retain this feature.
• Change the source of the radio to AUX-IN; SYNC
®
audio will start playing if SYNC
®
has been
activated.
• The display in the factory screen, or the optional AX-LCD (sold separately) will display the
SYNC
®
information.
• Listed below are the functions of the AX-LCD while using SYNC
®
:
• Arrow Up—Channel up (only in USB mode)
• Arrow Down—Channel down (only in USB mode)
• Enter—Selects current item on the screen
• Return/ESC—Exits to the previous screen
PROGRAMMING EXTRA FEATURES
For the steps below, the LED located inside the interface can only be seen while active. The
interface does not need to be opened to see the LED.
1. Start the vehicle.
2. Connect the AXDIS-FD2 harness to the wiring harness in the vehicle.
3. The LED will initially turn on solid Green, then turn off for a few seconds while it auto
detects the radio installed.
4. The LED will then flash Red up to (24) times indicating which radio is connected to the
interface, and then turn off for a couple of seconds. Pay close attention to how many Red
flashes there are. This will help in troubleshooting, if need be. Refer to the LED feedback
section for more information.
5.
After a couple seconds the LED will turn on solid Red while the interface auto detects the
vehicle. The radio will shut off at this point. This process should take 5 to 30 seconds
.
6. Once the vehicle has been auto detected by the interface, the LED will turn on solid Green,
and the radio will come back on, indicating programming was successful.
7. Test all functions of the installation for proper operation, before reassembling the dash. If
the interface fails to function, refer to Troubleshooting section.
Note:
The LED will turn on solid Green for a moment, and then turn off under normal
operation after the key has been cycled.
