AXDIS-FD2
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 11/22/24 INSTAXDIS-FD2
INTERFACE FEATURES
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties
TABLE OF CONTENTS
Connections ........................................................ 2-3
Installation .............................................................3
Programming .........................................................4
Extra features .........................................................4
Steering Wheel Control Settings (SWC)...........5-8
LED feedback ..................................................... 5
Changing Radio Type ........................................ 6
Remapping (SWC) Buttons .......................... 6-7
Dual Assignment Instructions ...................... 7-8
Troubleshooting.....................................................8
Ford Data Interface with SWC 2011-2019
APPLICATIONS
• Designed for non-amplified models
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (Retained Accessory Power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains SYNC
®
• Retains the factory AUX-IN jack
• Retains balance and fade • Micro-B USB updatable
FORD
Escape (w/4.3" screen) ............................................................. 2013-2019
Fiesta* (w/4.3" screen) ............................................................. 2014-2019
Focus* (w/4.2" screen) ..............................................................
2012-2014
**
Transit 150/250/350 (w/ AM/FM/CD) ............................................... 2015-2019
Transit Connect (w/AM/FM/CD/SYNC
®
radio) .............................. 2014-2016
* Without MyFord Touch
®
**For models without SYNC
®
, the AXSWC (sold separately) will be required to
retain the audio buttons on the steering wheel.
INTERFACE COMPONENTS
• AXDIS-FD2 interface • AXDIS-FD2 harness
• 16-pin harness • 3.5mm adapter
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
Visit AxxessInterfaces.com for more detailed information
about the product and up-to-date vehicle specific applications
Product Info
www.MetraOnline.com
MetraOnline.com may be used
to assist with dash assembly
instructions. Simply enter
your Year, Make, Model
vehicle into the vehicle fit
guide and look for the Dash
Kit Installation Instructions.
